Series 21i/210i - Model B Parameter manual Page 167

Parameter manual
B–63610EN/01
4. DESCRIPTION OF PARAMETERS
161
3671
Number of pitch error compensation point at the farthest end in the positive
direction if pitch error compensation is carried out on an axis of Cs contour con-
trol on the slave side during simple synchronous spindle control (for the first
spindle)
3672
Number of pitch error compensation point at the farthest end in the positive
direction if pitch error compensation is carried out on an axis of Cs contour con-
trol on the slave side during simple synchronous spindle control (for the second
spindle)
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Word
[Unit of data] Number
[Valid data range] 0 to 1023
This parameter is used if bit 1 (EPC) of parameter No. 3601 is set to 1, so
that pitch error compensation is carried out on an axis of Cs contour
control on the slave side during simple synchronous spindle control,
separately from that on the master side. Set the pith error compensation
data number to be assigned to the parameter of the spindle which becomes
the axis of Cs contour control on the slave side.
3676
Number of compensation point at the farthest end in the negative direction in a
movement in the negative direction if both–direction pitch error compensation is
carried out on an axis of Cs contour control on the slave side during simple
synchronous spindle control (first spindle)
3677
Number of compensation point at the farthest end in the negative direction in a
movement in the negative direction if both–direction pitch error compensation is
carried out on an axis of Cs contour control on the slave side during simple
synchronous spindle control (second spindle)
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
