FANUC Series 16i/18i/160i/180i/160is/180is-MODEL A PARAMETER MANUAL
FANUC Series 16i/18i/160i/180i/160is/180is-MODEL B PARAMETER MANUAL
FANUC Series 21i/210i/210is-MODEL A PARAMETER MANUAL
FANUC Series 21i/210i/210is-MODEL B PARAMETER MANUAL
Concerning the correction of Parameters of pitch error compensation
1.Type of applied technical documents
Name
FANUC Series 16i/18i/160i/180i/160is/180is-MODEL A PARAMETER MANUAL
FANUC Series 16i/18i/160i/180i/160is/180is-MODEL B PARAMETER MANUAL
FANUC Series 21i/210i/210is-MODEL A PARAMETER MANUAL
FANUC Series 21i/210i/210is-MODEL B PARAMETER MANUAL
Spec.No./Ed. B-63010EN/02 , B-63090EN/02 , B-63530EN/02 , B-63610EN/01
2.Summary of Change
Group Name/Outline
New, Add,
Correct,
Delete
Applicable
Date
Basic
Optional
Function
Unit
Maintenance
Parts
Notice
Correction The note of parameter No.3625 is replaced.
Another
1/2
PAGEEDT.
DATE
DESIGN
DESCRIPTION
TITLE
No.
FANUC Series 16i/18i/21i-A/B
PARAMETER MANUAL
Concerning the correction of Parameters of
pitch error compensation
B-63010EN/02-05 B-63090EN/02-04
B-63530EN/02-05 B-63610EN/01-04
01 02.09.20 Newly Registered
Previous page
Next page
