4. DESCRIPTION OF PARAMETERS

B–63610EN/01

206

5001

EVO

TPH

EVR

TAL

OFH

TLB

TLC

[Data type] Bit type

TLC Tool length compensation

0 : Tool length compensation A or B (Conforms to TLB in parameter

No.5001)

1 : Tool length compensation C

TLB Tool length compensation axis

0 : Always Z axis irrespective of plane specification (Tool length

compensation A)

1 : Axis perpendicular to plane specification (G17, G18, and G19) (Tool

length compensation B)

OFH Offset number of tool length compensation, cutter compensation and tool

offset

0 : Specifies the tool length compensation using an H code, and cutter

compensation C using a D code

Tool offset conforms to TPH in parameter No.5001#5.

1 : Specifies the tool length compensation, cutter compensation and tool

offset using H codes

TAL Tool length compensation C

0 : Generates an alarm when two or more axes are offset

1 : Not generate an alarm even if two or more axes are offset

EVR When a tool compensation value is changed in cutter compensation C

mode:

0 : Enables the change, starting from that block where the next D or H

code is specified.

1 : Enables the change, starting from that block where buffering is next

performed.

TPH Specifies whether address D or H is used as the address of tool offset

number (G45 to G48).

0 : D code

1 : H code

TPH is valid when OFH in parameter No.5001#2 is 0.

EVO Specifies whether an offset is effective in the next block to be buffered or

the next block for which an H code is specified when the offset value is

changed in tool length offset A or B.

0 : Next block in which an H code is specified.

1 : Next block to be buffered.

4.23

PARAMETERS OF

TOOL

COMPENSATION
