Series 21i/210i - Model B Parameter manual Page 267

Parameter manual
B–63610EN/01
4. DESCRIPTION OF PARAMETERS
261
VHD With system variables #5121 through #5124
0 : Tool position offset values (geometry offset values) are read.
1 : The amount of interrupt shift caused by a manual handle interrupt is
read.
D15 When tool compensation memory C is used, for reading or writing tool
offset values (for up to offset number 200) for D code (tool radius), the
same system variables, #2401 through #2800, as Series 15 are:
0 : Not used.
1 : Used.
D code
Offset number
Geometry offset
value
Tool wear com-
pensation value
1
2
:
200
#2401
#2402
:
#2600
#2601
#2602
:
#2800
NOTE
When the D15 parameter is set to 1, system variables #2500
through #2806, for workpiece reference point offset values,
cannot be used. Instead, use system variables #5201
through #5324.
#7
6005
#6 #5 #4 #3 #2 #1
ADR
#0
SQC
SQC
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Bit
SQC Calling a subprogram with its sequence number by the subprogram call
function is:
0 : Disabled.
1 : Enabled.
ADR Calling a subprogram with address E by the subprogram call function
using a custom macro and macro executor special code is:
0 : Disabled.
1 : Enabled.
Address E can be set for parameters Nos. 6090 and 6091.
#7
6006
#6 #5 #4 #3 #2 #1 #0
MLG
[Data type] Bit
MLG In conditional decision statements in custom macros, logical operations:
0 : Cannot be used.
1 : Can be used.
