Series 21i/210i - Model B Parameter manual Page 145

Parameter manual
B–63610EN/01
4. DESCRIPTION OF PARAMETERS
139
NOTE
1 The state where password 0 0 and password 0 keyword is
referred to as the locked state. When an attempt is made to
modify the password by MDI input operation in this state, the
warning message “WRITE PROTECTED” is displayed to
indicate that the password cannot be modified. When an
attempt is made to modify the password with G10
(programmable parameter input), P/S alarm No.231 is issued.
2 When the value of the password is not 0, the parameter
screen does not display the password. Care must be taken
in setting a password.
3211 Keyword
[Data type] 2–word axis
When the value set as the password (set in parameter No.3210) is set in
this parameter, the locked state is released and the user can now modify
the password and the value set in bit 4 (NE9) of parameter No.3202.
NOTE
The value set in this parameter is not displayed. When the
power is turned off, this parameter is set to 0.
3216 Increment in sequence numbers inserted automatically
Setting entry is acceptable.
[Data type] Word
[Valid data range] 0 to 9999
Set the increment for sequence numbers for automatic sequence number
insertion (when SEQ, #5 of parameter 0000, is set to 1.)
