Series 21i/210i - Model B Parameter manual Page 76

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63610EN/01
70
1451
Feedrate for F1 digit command F1
1452
Feedrate for F1 digit command F2
1453
Feedrate for F1 digit command F3
1454
Feedrate for F1 digit command F4
1455
Feedrate for F1 digit command F5
1456
Feedrate for F1 digit command F6
1457
Feedrate for F1 digit command F7
1458
Feedrate for F1 digit command F8
1459
Feedrate for F1 digit command F9
Setting entry is acceptable.
[Data type] 2–word
[Unit of data, valid range]
(1) When the F1U parameter (bit 0 of parameter No.1405) is 0
Valid data range
Increment system Units of data
IS–A, IS–B IS–C
Millimeter machine 0.1 mm/min 6 to 150000 6 to 120000
Inch machine 0.01 inch/min 6 to 60000 6 to 48000
Rotation axis 0.1 deg/min 6 to 150000 6 to 120000
(2) When the F1U parameter (bit 0 of parameter No.1405) is 1
Valid data range
Increment system Units of data
IS–A, IS–B IS–C
Millimeter machine 1 mm/min 6 to 15000 6 to 12000
Inch machine 0.1 inch/min 6 to 6000 6 to 4800
Rotation axis 1 deg/min 6 to 15000 6 to 12000
These parameters set the feedrates for 1–digit feed commands F1 to F9.
When an 1–digit feed command is specified, and the feedrate is changed
by turning the manual pulse generator, the parameter–set value also
changes accordingly.
