4. DESCRIPTION OF PARAMETERS
B–63610EN/01
340
For axes under simple synchronization control, when the external
machine coordinate system shift is performed for the master axis, it can
also performed for the slave axis simultaneously.
NOTE
The simple synchronous signal must be manipulated.
Carefully turn the simple synchronous signal on and off
because the machine may move at that time.
SMA When bit 4x (APZx) of parameter No. 1015 is turned off for one axis under
simple synchronous control, APZx for the other axis under simple
synchronous control is:
0 : Not turned off.
1 : Turned off.
When an axis for which the simple synchronous axis parameter is set is
under simple synchronous control, the simple synchronous signal is
turned on for the axis.
#7
8303
SOFx
#6 #5 #4 #3 #2 #1
ATSx
#0
ATEx
NOTE
After this parameter has been set, the power must be turned
off then on again for the setting to become effective.
[Data type] Bit axis
ATEx In simple synchronous control, automatic setting for grid positioning is:
0 : Disabled.
1 : Enabled.
ATSx In simple synchronous control, automatic setting for grid positioning is:
0 : Not started.
1 : Started.
NOTE
When starting automatic setting for grid positioning, set
ATSx to 1. Upon the completion of setting, ATSx is
automatically set to 0.
SOFx In simple synchronous control, the synchronization function is:
0 : Not used.
1 : Used.
NOTE
Set this parameter on the master axis side.
