4. DESCRIPTION OF PARAMETERS

B–63610EN/01

224

5141

Finishing allowance in the multiple repetitive canned cycle G76

[Data type] 2–word

[Unit of data]

Increment system IS–B IS–C Unit

Metric input 0.001 0.0001 mm

Inch input 0.0001 0.00001 inch

[Valid data range] 1 to 99999999

This parameter sets the finishing allowance in multiple repetitive canned

cycle G76.

5142

Repetition count of final finishing in multiple repetitive canned cycle G76

[Data type] 2–word

[Unit of data] Cycle

[Valid data range] 1 to 99999999

This parameter sets the repetition count in multiple repetitive canned

cycle G76.

5143

Tool nose angle in multiple repetitive canned cycle G76

[Data type] 2–word

[Unit of data] Degree

[Valid data range] When FS10/11 format is used: 0 to 120

When FS10/11 format is not used: 0, 29, 30, 55, 60, 80

This parameter sets the tool nose angle in multiple repetitive canned cycle

G76.

5160

#6 #5 #4 #3 #2

NOL

OLS

[Data type] Bit

OLS When an overload torque signal is received in a peck drilling cycle of a

small diameter, the feed and spindle speed are

0 : Not changed.

1 : Changed.

NOL When the depth of cut per action is satisfied although no overload torque

signal is received in a peck drilling cycle of a small diameter, the feed and

spindle speed are:

0 : Not changed.

1 : Changed.

4.24.4

Parameters of Peck

Drilling Cycle of a

Small Diameter
