4. DESCRIPTION OF PARAMETERS
B–63610EN/01
246
5335
Time constant for the spindle and tapping axis in second spindle extraction
operation (first–stage gear)
5336
Time constant for the spindle and tapping axis in second spindle extraction
operation (second–stage gear)
[Data type] Word
[Unit of data] ms
[Valid data range] 0 to 4000
Each of these parameters is used to set a linear acceleration/deceleration
time constant for the spindle and tapping axis in extraction operation
during rigid tapping on a gear–by–gear basis.
NOTE
This parameter is enabled when both the TDR parameter
(bit 2 of parameter No.5201) and the SPR parameter (bit 1
of parameter No.5204) are set to 1.
5341
Position control loop gain for the spindle and tapping axis in rigid tapping using
the second spindle (common to all the gears)
5342
Position control loop gain for the spindle and tapping axis in rigid tapping using
the second spindle (first–stage gear)
5343
Position control loop gain for the spindle and tapping axis in rigid tapping using
the second spindle (second–stage gear)
NOTE
After these parameters have been set, the power must be
turned off then back on for the settings to become effective.
[Data type] Word
[Unit of data] 0.01 s
–1
[Valid data range] 1 to 9999
Each of these parameters is used to set a position control loop gain for the
spindle and tapping axis in rigid tapping using the second spindle.
NOTE
1 To use a varied loop gain on a gear–by–gear basis, set
parameter No.5341 to 0, and set a loop gain for each gear
in parameters No.5342 and No.5343.
2 This parameter is enabled when the SPR parameter (bit 1
of parameter No.5204) is set to 1.
