Series 21i/210i - Model B Parameter manual Page 391

Parameter manual
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Aug.03.05 Desig. Apprv.
2/2
FANUC Series 0i - B, 21i - A/B
Parameter Manual
Correction of parameter No.1850 description
B-63840EN/03-04 B-63090EN/02-05
B-63610EN/01-06
Outline
The data setting range of parameter No.1850 (Grid shift for each axis) is corrected.
Detail
The data setting range of parameter No.1850 (Grid shift for each axis) is corrected as follows.
Before correction )
[Valid data range] 0 to 99999999
To shift the reference position, the grid can be shifted by the amount set in
this parameter.
Up to the maximum value counted by the reference counter can be specified
as the grid shift.
After correction )
[Valid data range] ( - Reference counter value ) to ( + Reference counter value )
To shift the reference position, the grid shift value is set in this parameter for
each axis.
Up to the maximum value counted by the reference counter can be specified
as the grid shift.
