Series 21i/210i - Model B Parameter manual Page 16

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63610EN/01
10
PRB A digitizing probe is:
0: Not attached.
1: Attached.
When the probe attachment signal PRBST<G006#5> is not used in
digitizing, this setting parameter can be used to notify the CNC of probe
attachment state.
NOTE
1 This parameter has the same function as the probe
attachment signal PRBST<G006#5>.
If the machine has ladder and switch for operating the probe
attachment signal PRBST<G006#5>, set this parameter to
0 to protect against incorrect operations.
2 Set this parameter as follows:
– Before attaching a probe connector, turn off the power
to the CNC. After attaching the probe connector, turn on
the power, and then set this parameter to 1.
– Before detaching the probe connector, set this
parameter to 0, and then turn off the power to the CNC.
#7
0002
#6 #5 #4 #3 #2 #1 #0
RDG
RDGSJZ
Setting entry is acceptable.
[Data type] Bit
RDG Remote diagnosis is
0: Not performed.
1: Performed.
To use an RS–232C serial port for performing remote diagnosis, connect
and setup the modem, cable, and the like, then set 1 in this parameter. When
using a modem card, the setting is not necessary.
SJZ Manual reference position si performed as follows:
0 : When no reference position has been set, reference position return is
performed using deceleration dogs. When a reference position is
already set, reference position return is performed using rapid traverse
and deceleration dogs are ignored.
1 : Reference position return is performed using deceleration dogs at all
times.
Note
SJZ is enabled when bit 3 (HJZ) of parameter No.1005 is
set to 1. When a reference position is set without a dog,
(i.e. when bit 1 (DLZ) of parameter No.1002 is set to 1 or
bit 1 (DLZx) of parameter No.1005 is set to 1) reference
position return after reference position setting is
performed using rapid traverse at all times, regardless of
the setting of SJZ.
