Alpha Series AC Servo Amplifier Descriptions Page 102

Descriptions

Page of 699

/ 699

4. SPECIFICATIONS

B–65162E/03

Table.4.3.2 Servo Amplifier Modules

Model Weight

SVM1–12,20 2.2Kg

SVM1–40S,40L,80 4.8Kg

SVM1–130 6.5Kg

SVM1–240,360 10.7Kg

Dynamic brake module (DBM) for SVM1–240, 360 5.4Kg

SVM2–12/12,12/20,20/20 2.8Kg

SVM2–12/40,20/40,40/40 5.5Kg

SVM2–40/80,80/80,40L/40L 7.0Kg

SVM3–12/12/12,12/12/20,12/20/20,20/20/20 4.1Kg

SVM3–12/12/40,12/20/40,20/20/40 6.5Kg

SVM1–20HV,40HV,60HV 6.0Kg

SVM2–20/20HV,20/40HV

SVM2–20/60HV,40/40HV,40/60HV,60/60HV

7.5Kg

Table.4.3.3 Spindle Amplifier Modules

Model Weight

SPM–2.2 (TYPE1, 2, 4), SPMC–2.2 4.9Kg

SPM–5.5 (TYPE1, 2, 4), SPMC–5.5, 11 6.1Kg

SPM–11 (TYPE1, 2, 4) 5.4Kg

SPM–15, 26, 30 (TYPE1, 2, 3, 4), SPM–11 (TYPE3)

SPMC–15, 22, 26

10.7Kg

SPM–45 (TYPE1, 2, 3, 4) 22Kg

SPM–11HV (TYPE1, 2, 4) 4.6Kg

SPM–15HV, 26HV, 45HV (TYPE1, 2, 4) 11Kg

SPM–75HV (TYPE1, 2, 3, 4) 22Kg

4.3.2

Servo Amplifier

Modules

4.3.3

Spindle Amplifier

Modules
