11. OPTION RELATED TO SPINDLE

469

(b) Gear selection signals indicating the gear state that allows

gear–dependent parameter selection (GR1, GR2, GR21, GR10,

GR20, GR30)

signal: SFR)

NOTE

1 With the analog interface spindle, the TLML signal is

entered for rigid tapping. With the α series and αC series

spindles, however, set the TLML signal to 0.

2 For details of the signals, refer to the CNC connection

manual.

(3) Gear Switch Signals for FS16 and FS0

With FS16 and FS0, two methods of gear switching are supported.

(a) T–type gear switching (T/TT series, or M series with the constant

surface speed option)

With this method, parameters used internally by the CNC are

switched according to the GR1 and GR2 signals (GR21 when the

second spindle is used) sent from the PMC to the CNC.

(b) M–type gear switching (standard M series)

With this method, the CNC determines the number of gear stages

from the CNC parameter setting and specified S value, and the

parameters used internally by the CNC are switched. Moreover,

the number of gear stages to be switched is sent from the CNC

to the PMC with the GR10, GR20, and GR30 signals.

For details, refer to the description of S the function in the

connection manual for each CNC. For details of the parameters,

refer to the operator’s manual.

The table below lists the parameters related to the gear switch

signals.

Item FS0–M FS16–M

Maximum gear–dependent spindle speed

(When the motor rotates at maximum speed = 10V)

0541

0539

0555

3741

3742

3743

Maximum spindle motor clamp speed 0542 3736

Minimum spindle motor clamp speed 0543 3735

Gear switch method selection

Spindle motor speed at gear 1–2 switch point

Spindle motor speed at gear 2–3 switch point

0035#6

0585

0586

3706#2

3751

3752

Gear switch point change selection at tapping time

Spindle motor speed at gear 1–2 switch point

Spindle motor speed at gear 2–3 switch point

0012#6

0540

0556

3706#3

3761

3762
