Alpha Series AC Servo Amplifier Descriptions Page 665

Descriptions
TITLE
DRAW.
No.
6 / 40
Page
FANUC LTD
DESCRIPTIONDESIGNDATE
EDIT
Power Failure Back-up Module
(with control power backup function)
DESCRIPTIONS
B-65162E/03-08
TMS01/032E
2.2.8 Cables
(1) Jumpers for connection between Servo Amplifiers (PSM, SVM and SPM)
See “SERVO AMPLIFIER a series DESCRIPTIONS” B-65162E/03.
(2) Cables for connection between Power Failure Backup Module and Servo Amplifiers
Category Name Ordering number Length Remarks
A06B-6082-K808 200mm
A06B-6082-K809 150mm
Optional Connection
cables
between
modules
A06B-6082-K810 100mm
Including following cables
K59 : For +24V Power Supply
K63 : For Interface between
Modules
2.2.9 Breaker
Category Name Ordering number Rated current Remarks
Optional Breaker1 See DESCRIPTIONS (B-65162E/03).
Breaker2 A06B-6077-K106 5A EA33/5 (Fuji Electric)
Breaker4 — 3A EA33/3 (Fuji Electric)
3. SPECIFICATIONS
(1) Power Supply : Main circuit (DC Link Voltage) DC283V to DC325V +10% -15% (note 1)
: Control power DC24V ±5% (note 2)
(2) Power Failure Detection Signal
: Input voltage (CX12 input) AC200V/AC220V/AC230V +10% -15%
3 phase 50Hz/60Hz ± 1Hz
: Detection voltage AC140V (typical)
: Detection filter time constant 7msec (preset)
(adjustable from 0msec to 15msec)
(3) Power Supply Ability for Main Power when power failure occurs
: 500J per one Sub Module C (when input voltage is AC200V)
: Maximum number of Sub Module C that can be connected is 8. ( note 3 )
(4) Maximum Regeneration Power (Resistor Regeneration)
: 20kW One Sub Module R is connected (8Ω)
: 40kW Two Sub Module R are connected parallel (4Ω)
(5) Power supply capacity for Control Power
: Maximum 1kVA (including the power supplied to PSM)
(6) Ambient Temperature
: 0°C to 55°C
(note 1) On condition that input voltage to PSM is AC200V/AC220V/AC230V (+10%, -15% ).
Power Failure Backup Module can’t be connected to PSM-HV and PSMV.
(note 2) Supplied form PSM
(note 3) The supply energy from Sub Module C varies very much with some condition.
It is necessary to take enough margins when considering the energy from Sub
Module C and selecting the number of Sub Module C.
See “How to define the number of Sub Module C” (B-65162E/03-04).
