11. OPTION RELATED TO SPINDLE

425

D The rotating direction of the spindle motor is specified by setting a

parameter.

D When the motor rotates first after the power has been turned on, it

rotates at the orientation speed and stops in a specified position after

the one rotation signal has been captured. When it rotates next or later,

it stops in the specified position within one rotation.

D With the spindle orientation function in which a stop position is

externally specified, if the data of SHA11-00 (spindle orientation stop

position command) is decided in a second or later stop operation, the

motor stops at a position ([one-rotation signal position] + [data

specified by SHA11-00] + [PRM4077]) shifted by the value seized on

a rising edge of ORCMA (spindle orientation command).

Stop

 and 

D Stopping in a specified position using the stop position external setting

type spindle orientation function

D The rotating direction of the spindle motor is specified by the

following command: (1) rotating direction command when spindle

orientation stop position is changed (ROTA) or, (2) shortcut command

when spindle orientation stop position is changed (NRROA).

NOTE

The spindle orientation stop position change command

INDXA is valid only when the spindle orientation command

ORCMA is set to 1.

The table below lists the parameters related to spindle orientation using

a position coder. Refer to the Parameter Descriptions for details.

Parameter No.

Description

FS0 FS15 FS16

Description

Orientation function setting

6515#0 3015#0 4015#0

Whether spindle orientation is used (Set to 1.)

(CNC software option is necessary.)

0080

#3,#2

5609

#3,#2

3702

#3,#2

Whether to use the spindle orientation function of external stop position

setting type. (#2: First spindle, #3: Second spindle)

Setting related to the position coder signal

6501#2 3001#2 4001#2 Whether a position coder signal is used (Set to 1.)

6500#2 3000#2 4000#2 Mounting orientation for the position coder

6500#0 3000#0 4000#0 Rotational direction of the spindle and motor

6503#0 3003#0 4003#0

Selection of position coder method or magnetic sensor method spindle

orientation (0 for a position coder method)

6503

#7, 6, 4

3003

#7, 6, 4

4003#

7, 6, 4

Setting of the position coder signal

6517#2 3017#2 4017#2

Function for detecting position coder one–rotation signal at normal rota-

tion

6598 3098 4098 Position coder signal detection maximum speed

11.1.1.7

Parameters
