11. OPTION RELATED TO SPINDLE

B–65162E/03

426

Parameter No.

Description

FS0

Description

FS16FS15

Gear ratio setting

6556 to

6559

3056 to

3059

4056 to

4059

Gear ratio between the spindle and motor

(selected by DI signals CTH1A and CTH2A)

Setting of a rotation direction at orientation time

6503

#3, 2

3003

#3, 2

4003

#3, 2

Rotational direction for spindle orientation

Setting of a stop position shift amount

6531 3031 4031

Stop position for position coder method orientation

(This parameter is invalid when the function for externally setting the

stop position or externally setting incremental commands is used.)

6577 3077 4077 Shift of spindle orientation stop position

Setting related to gain at orientation time

6560 to

6563

3060 to

3063

4060 to

4063

Position gain for orientation

(selected by DI signals CTH1A and CTH2A)

6542

6543

3042

3043

4042

4043

Velocity loop proportional gain for orientation

(selected by DI signal CTH1A)

6550

6551

3050

3051

4050

4051

Velocity loop integral gain for orientation

(selected by DI signal CTH1A)

6564 3064 4064 Change rate for the position gain after spindle orientation

Setting related to gain at orientation time (Continued)

6584 3084 4084

Setting related to orientation speed

6538 3038 4038 Orientation speed

6576 3076 4076 Orientation–time motor speed limit ratio

Setting related to the orientation completion signal

6575 3075 4075 Detection level for the spindle orientation completion signal

6276 3456 4312

Detection level for the approach signal for position coder method

orientation

Others

6517#7 3017#7 4017#7 Shorter route function for orientation from stop state

(1) Overview

The high–speed orientation function reduces spindle orientation time by:

1 Making full use of the motor deceleration capability

2 Increasing the gain of the position loop
