Alpha Series AC Servo Amplifier Descriptions Page 501

Descriptions

Page of 699

/ 699

B–65162E/03

11. OPTION RELATED TO SPINDLE

481

The tables below list the parameters relating to Cs contouring control.

Refer to the Parameter Manual and each CNC manual for details.

Parameter No.

Description

FS0 FS15 FS16

Description

Setting of axis allocation and so forth

3rd axis 4th axis 1804#7 1023 Setting of the axis for which Cs contouring control is performed

0037#7 1804#0 Select ”High–resolution pulse coder not used.”

0037#3, 2 1815#1 1815#1 Select ”Separate pulse coder not used”.

0021#3, 2 1815#5 1815#5 Select ”Other than absolute position detector.”

0102 0103 1820 1820 Set the command multiplication to 2 (that is, x1)

Setting of an in–position width and positional deviation limit

0502 0503 1827 1826 In–position width

0506 0507 1828 1828 Limit on position error during moving

0595 0596 1829 1829 Limit on position error during stop

1830 Limit on position error during servo off

0332 0333 1832 1832 Limit on position error for feed stop

Setting of a feedrate and acceleration/deceleration time constant

0520 0521 1420 1420 Rapid feed rate

0527 1422 1422 Maximum cutting feedrate

0561 0562 1423 1423 Jog feedrate

0524 0525 1620 1620 Time constant for linear acceleration/deceleration in rapid feed

0635 1622 1628

Time constant for linear acceleration/deceleration in cutting feed (op-

tion)

0603 0604 1624 1624 Time constant for exponential acceleration/deceleration in jog feed

αSetting related to the spindle sensors (MZ sensor, BZ sensor)

3001#5 4001#5

Whether to use a high–resolution magnetic pulse coder. (To be set to

3001#6 4001#6 Setting for using a position detection signal for speed detection

3001#7 4001#7 Position detector mounting direction

3000#0 4000#0 Spindle and motor rotation direction

3003#1 4003#1 Use of an MZ sensor or BZ sensor (built–in motor). (To be set to 1)

3003

#7,6,4

4003

#7,6,4

Position detector type setting

3004#1 4004#1 Whether to use a BZ sensor on the spindle side

11.3.6

Parameters
