Alpha Series AC Servo Amplifier Descriptions Page 245

Descriptions

Page of 699

/ 699

B–65162E/03

9.CONNECTION

225

For an explanation of how to connect each model, see the corresponding

description, below.

Model/drawing number TYPE A TYPE B FSSB

SVM1

(excluding the SVM1–240 and –360)

A06B–6079–H1VV

(A) (B) –––

SVM1–240, SVM1–360

A06B–6079–H107, H108

(A), (D) (B), (D) –––

SVM1–240 (two of which are used)

A06B–6079–H107

(A), (E) (B), (E)

SVM2

A06B–6079–H2VV

(A) (B) –––

SVM3

A06B–6079–H3VV

(A) ––– –––

SVM3

A06B–6080–H3VV

––– (B) –––

SVM1–HV

A06B–6085–H1VV

(A) (B) –––

SVM2–HV

A06B–6085–H2VV

(A) (B) –––

SVM1

(excluding the SVM1–240 and –360)

A06B–6096–H1VV

––– ––– (C)

SVM1–240, SVM1–360

A06B–6096–H107, H108

––– ––– (D)

SVM1–240 (two of which are used)

A06B–6096–H107

––– ––– (E)

SVM2

A06B–6096–H2VV

––– ––– (C)

SVM3

A06B–6096–H3VV

––– ––– (C)

SVM1–HV

A06B–6097–H1VV

––– ––– (C)

SVM2–HV

A06B–6097–H2VV

––– ––– (C)

NOTE

Items (A) to (E) are described on the following pages.

(A) TYPE A interface (Example: SVM2)

(B) TYPE B interface (Example: SVM2)

(D) FSSB interface (Example: SVM1–240 and –360)

(E) FSSB interface (Example: Two SVM1–240 units are used.)
