Alpha Series AC Servo Amplifier Descriptions Page 632

Descriptions
B–65162E/03
F. SPECIFICATIONS OF CABLES
APPENDIX
613
Use
Sym-
bol
Specification
FANUC specification
(complete cable)
α22/3000,
α30/2000,
α30/3000,
α40, αC22,
αL25 αL50
K21
A06B–6079–K804
(Cable length : 14m)
αL25
,
αL50
,
αM22,
αM30
(motor
power line)
K21
A06B–6079–K805
(Cable length : 14m)
α100/2000,
α150/2000,
α300/1200,
α400/1200,
α65/2000
(motor
power line)
K21
For
SVM–DBM
(power line)
K26
NOTE
1 Heat–resistant cable:
Shinko Electric Industries Co., Ltd.
Contact: 03(3492)0073 Tokyo Sales Office
06(363)2691 Osaka Headquarters
Cable conforming to IEC (oil–resistant PVC)
2 Crimp terminal: Nichifu Contact: 03(3452)7381
8–4S
3 Heat–resistant cable: Furukawa Electric Co., Ltd. Contact:
03(3286)3144
LMFC (Fire–retardant Polyflex electric cable, Maximum
allowable conductor temperature: 105°C)
A66L–0001–0410#410 (FNC–077) (Note 1)
SVM side (TB2)
T8–4S (Note 2)
φ19.7
Motor side
Connector:
JL04V–6A24–10SE
(G)–EB
Cable clamp:
JL04–2428CK–(17)
A66L–0001–0410#410 (FNC–077) (Note 1)
SVM side (TB2)
T8–4S (Note 2)
φ19.7
Motor side
Connector:
JL04V–8A24–10SE
(G)–EB
Cable clamp:
JL04–2428CK–(17)
Heat resistive vinyle cable (Note 3) 22mm
2
(7/20/0.45)
SPM side (TB2)
T22–6
φ5.2
Motor side
T22–8
Heat resistive vinyle cable (Note 3) 5.5mm
2
(30/0.45)
SPM side (TB2)
T5.5–6
φ5.2
Dynamic brake side (T1)
T22–8
