Alpha Series AC Servo Amplifier Descriptions Page 156

Descriptions
6. HEAT DISSIPATION
B–65162E/03
136
When a motor other than those listed below is used, its heat output should
be assumed to be that of a listed motor with a higher rated current.
Table.6.2.2 (a) SVM1–HV (One Axis)
Ordering number Motor used
Total heat
Remaining heat in cabinet
Name
A06B–6085
A06B–6097
L–axis M–axis
Total
heat
dissipation
Natural
ventilation
Forced air
cooling
SVM1–20HV –H102 α6/3000HV 32W 22W
SVM1–40HV –H103 α12/3000HV 57W 34W
SVM1–60HV –H104 αM30/3000HV 88W 45W
Table.6.2.2 (b) SVM2–HV (Two Axes)
Ordering number Motor used
Total heat
Remaining heat in cabinet
Name
A06B–6085
A06B–6097
L–axis M–axis
Total
heat
dissipation
Natural
ventilation
Forced air
cooling
SVM2–20/20HV –H201 α6/3000HV α6/3000HV 55W 36W
SVM2–20/40HV –H202 α6/3000HV α12/3000HV 75W 42W
SVM2–20/60HV –H203 α6/3000HV αM30/3000HV 111W 58W
SVM2–40/40HV –H204 α12/3000HV α12/3000HV 95W 48W
SVM2–40/60HV –H205 α12/3000HV αM30/3000HV 131W 65W
SVM2–60/60HV –H206 αM30/3000HV αM30/3000HV 161W 75W
6.2.2
Servo Amplifier
Modules
Previous page
Next page
