11. OPTION RELATED TO SPINDLE

463

The table below lists the parameters related to spindle orientation using

a magnetic sensor. Refer to the Parameter Manual for details.

Parameter No.

Description

FS0 FS15 FS16

Description

Orientation function setting

6515#0 3015#0 4015#0

Whether spindle orientation is used (Set to 1.)

(CNC software option is necessary.)

Setting related to the magnetic sensor signal

6501#3 3001#3 4001#3 Mounting orientation for the magnetic sensor

6500#0 3000#0 4000#0 Rotational direction of the spindle and motor

6503#0 3003#0 4003#0

Selection of a position coder method magnetic sensor method spindle

orientation (1 for a magnetic sensor method)

6578 3078 4078 MS signal constant

6579 3079 4079 MS signal gain adjustment

Gear ratio setting

6556 to

6559

3056 to

3059

4056 to

4059

Gear ratio between the spindle and motor

(selected by DI signals CTH1A and CTH2A)

Setting of a rotation direction at orientation time

6503

#3, 2

3003

#3, 2

4003

#3, 2

Rotational direction for spindle orientation

Setting of a stop position shift amount

6577 3077 4077 Shift of spindle orientation stop position

Setting related to gain at orientation time

6560 to

6563

3060 to

3063

4060 to

4063

Position gain for orientation

(selected by DI signals CTH1A and CTH2A)

6542

6543

3042

3043

4042

4043

Velocity loop proportional gain for orientation

(selected by DI signal CTH1A)

6550

6551

3050

3051

4050

4051

Velocity loop integral gain for orientation

(selected by DI signal CTH1A)

6564 3064 4064 Change rate for the position gain after spindle orientation

6584 3084 4084 Motor voltage for spindle orientation

Setting related to orientation speed

6576 3076 4076 Motor speed regulation rate for spindle orientation

Setting related to the orientation completion signal

6575 3075 4075 Detection level for the spindle orientation completion signal

11.1.5.7

Parameters
