3. HOW TO SELECT THE POWER SUPPLY MODULE

B–65162E/03

Maximum number of modules that can be connected

SVM

SVM1

SVM2

SVM3

SPM

SPMC

(1) When two α1/3000 servo motors and one α2 spindle motor are used

Servo motor α1/3000

Continuous rated output : 0.3 kW

Maximum output at acceleration : 0.9 kW

Spindle motor

α2

Continuous rated output : 2.2 kW

Maximum output at acceleration : 4.44 kW

Rated output capacity of a power supply module y Σ spindle motor

continuous rated output 1.15 + Σ servo motor continuous rated

output 0.6

= 2.2 1.15 + 0.3 2 0.6

= 2.89 Condition 1

Maximum output capacity of the power supply module y Σ

maximum output of the spindle motor at acceleration + Σ maximum

output of the servo motors at acceleration (simultaneous

acceleration/deceleration)

= 4.44 + 0.9 2

= 6.24 Condition 2

According to conditions 1 and 2, PSMR–3 is selected as the power

supply module.

(2) When two α2/2000 servo motor and one α6/2000 servo motor, and

one α3 spindle motor are used

Servo motor α2/2000

Continuous rated output : 0.4 kW

Maximum output at acceleration : 1.1 kW

3.4.4

Example of Selecting a

Power Supply Module

(PSMR)
