12. DETECTORS FOR THE SPINDLE
561
(2) Absolute Maximum Ratings
Table.12.3.2 (b) Absolute Maximum Ratings
Item Specifications
Power supply voltage 0V to +18V
Operating temperature 0_C to +50_C
Humidity 30% to 90% RH (no condensation)
(3) Electrical Specifications
Table.12.3.2 (b) Absolute Maximum Ratings
Item Specifications
Power supply voltage DC15V"5%
Current consumption 100mA or less
Table.12.3.2 (c) Electrical Specifications
Channel Signal
CH 1 1/rev (MSA–MSB)
CH 2 1/rev (LSA–LSB)
(4) Output Pin Configuration
Table.12.3.2 (d) Output Pin Configuration
Pin A B C D E F
Signal name MSA 0V +15V MSB LSB LSA
