2. CONFIGURATION AND ORDERING INFORMATION

B–65162E/03

30

– For servo amplifier module

Category Name Ordering number Remarks

Standard

Other than SVM1–240, 360 A06B–6073–K250 3.2A/48V

Standard

SVM1–240, 360 A06B–6073–K252 3.2A/48V,0.5A/250V

– Fuse configuration

Configuration of A06B–6073–K250

Manufacturer Part number Specification Use

Daito Communication Apparatus Co., Ltd. LM32C 3.2A/48V

For short–circuit protection of

24–VDC control power supply

Configuration of A06B–6073–K252

Manufacturer Part number Specification Use

Daito Communication Apparatus Co., Ltd. LM32C 3.2A/48V

For short–circuit protection of

24–VDC control power supply

Daito Communication Apparatus Co., Ltd. HM05 0.5A/250V

For short–circuit protection of

200VAC for cooling fan

Configuration of A06B–6077–K250

Manufacturer Part number Specification Use

Daito Communication Apparatus Co., Ltd. HM20 2A/250V

For short–circuit protection of

200VAC for cooling fan

Daito Communication Apparatus Co., Ltd. HM50 5A/250V

For short–circuit protection of

200–VAC control power supply

Configuration of A06B–6081–K250

Manufacturer Part number Specification Use

Daito Communication Apparatus Co., Ltd. HM50 5A/250V

For short–circuit protection of

200–VAC control power supply

Configuration of A06B–6098–K250

Manufacturer Part number Specification Use

Daito Communication Apparatus Co., Ltd. HM20 2A/250V

For short–circuit protection of

200VAC for cooling fan

Daito Communication Apparatus Co., Ltd. HM50 5A/250V

For short–circuit protection of

200–VAC control power supply

Fuji Electric Co., Ltd. CR6L–100UL 100A/600V

For short–circuit protection of

400–VAC main circuit (Note)

NOTE

For the AC reactor unit
