Alpha Series AC Servo Amplifier Descriptions Page 664

Descriptions

Page of 699

/ 699

TITLE

DRAW.

No.

5 / 40

Page

FANUC LTD

DESCRIPTIONDESIGNDATE

EDIT

Power Failure Back-up Module

(with control power backup function)

DESCRIPTIONS

B-65162E/03-08

TMS01/032E

2.2 Ordering Information

2.2.1 Power Failure Backup Module

Category Name Ordering number Remarks

Standard Power Failure Backup

Module

A06B-6077-H002 with control power backup

function

2.2.2 Sub Module C

Category Name Ordering number Remarks

Standard Sub Module C

(Capacitor Module)

A06B-6077-H010

2.2.3 Sub Module R

Category Name Ordering number Remarks

Standard Sub Module R

(Discharge Unit)

A06B-6089-H712 8Ω/1200W

2.2.4 PSM for Power Failure Backup Module (with control power backup function)

Category Name Ordering number Remarks

Standard PSM-5.5 A06B-6077-H106#BM

PSM-11 A06B-6077-H111#BM

PSM-15 A06B-6087-H115#BM

PSM-26 A06B-6087-H126#BM

PSM-30 A06B-6087-H130#BM

PSM-37 A06B-6087-H137#BM

PSM-45 A06B-6087-H145#BM

PSM-55 A06B-6087-H155#BM

PSM selection method is as same as the

normal type PSM. Select PSM according

to the section 3.3 of DESCRIPTIONS

(B-65162E/03) and add “#BM” to the

end of the ordering number of selected

PSM External dimension is as same as

the normal type PSM.

2.2.5 Connectors

Category Name Ordering number Remarks

Standard Connectors A06B-6077-K212 Crimp type CX12,CX13,CX14, CX15

A06B-6077-K213 Solder type CX16,CX17, CX24,JX1A

2.2.6 Fuses

Category Name Ordering number Remarks

Standard Fuses A06B-6077-K255 FU1,FU2 (10A), FU3(3.2A)

2.2.7 Supplement Capacitor Unit

Category Name Ordering number Remarks

Optional Supplement Capacitor Unit A42L-0001-0381 Refer to “8.1(5)”

A06B-6077-H010

02 99.06.21 2.2.7 Ordering number changed.

02 99.06.21 2.2.4 PSM-37 added.
