2. CONFIGURATION AND ORDERING INFORMATION

Magnetic sensor for orientation

Category Name Ordering number Remarks

Not specified, standard A57L–0001–0037 Type II, 12,000min

–1

Magnetic sensor N A57L–0001–0037#N Type II, 12,000min

–1

Magnetic sensor NIP A57L–0001–0037#NIP

Type II, 12,000min

–1

Water–proof connector specification

Magnetic sensor P A57L–0001–0037#P Type III, 12,000min

–1

Magnetic sensor PIP A57L–0001–0037#PIP

Type III, 12,000min

–1

Water–proof connector specification

Magnetic sensor Q A57L–0001–0037#Q Type IV, 20,000min

–1

Magnetic sensor QIP A57L–0001–0037#QIP

Type IV, 20,000min

–1

Water–proof connector specification

Magnetic sensor R A57L–0001–0037#R Type V, 20,000min

–1

Magnetic sensor RIP A57L–0001–0037#RIP

Type V, 20,000min

–1

Water–proof connector specification

Optional

Magnetic sensor S A57L–0001–0037#S Type VI, 15,000min

–1

Magnetic sensor SIP A57L–0001–0037#SIP

Type VI, 15,000min

–1

Water–proof connector specification

Magnetic sensor T A57L–0001–0037#T Type VII, 15,000min

–1

Magnetic sensor TIP A57L–0001–0037#TIP

Type VII, 15,000min

–1

Water–proof connector specification

Magnetic sensor U A57L–0001–0037#U Type VIII, 20,000min

–1

Magnetic sensor UIP A57L–0001–0037#UIP

Type VIII, 20,000min

–1

Water–proof connector specification

Magnetic sensor U1 A57L–0001–0037#U1 Type IX, 15,000min

–1

Magnetic sensor U1IP A57L–0001–0037#U1IP

Type IX, 15,000min

–1

Water–proof connector specification

Magnetic sensor U2 A57L–0001–0037#U2 Type X, 15,000min

–1

Magnetic sensor U2IP A57L–0001–0037#U2IP

Type X, 15,000min

–1

Water–proof connector specification
