Descriptions
2. CONFIGURATION AND ORDERING INFORMATION
B–65162E/03
14
(1) Power Supply Module (PSM)
Category Name Ordering number
External dimensions
(H x W x D mm)
Remarks
PSM–5.5 A06B–6077–H106 38090307
PSM–11 A06B–6077–H111 38090307
(Note)
PSM–15 A06B–6087–H115
Standard
PSM–26 A06B–6087–H126
38090307
PSM–30 A06B–6087–H130
38090307
PSM–37 A06B–6087–H137
PSM–45 A06B–6087–H145 380300307
(Note)
See Chapter 3 for details of how to select the power supply module.
NOTE
PSM–11 and PSM–45 require forced air cooling from the outside. See (7) in Section 2.2.3 and
Chapter 7.
(2) Power Supply Module (PSMR)
Category Name Ordering number
External dimensions
(H x W x D mm)
Remarks
PSMR–3 A06B–6081–H103 38060172
PSMR–5.5 A06B–6081–H106 38060307
When selecting a PSMR, see Section 3.4.
NOTE
For the PSMR, a regenerative discharge unit is required. See (8) in Section 2.2.3, Section
3.4.5, and Section 8.1.7.
2.2
ORDERING
INFORMATION
2.2.1
200–V Input Series
