5. INSTALLATION

B–65162E/03

116

To satisfy the EMC Directive, the installation of a noise filter is required

in the input section of the power magnetics cabinet.

The rated current of the noise filter being used is determined according

to the type of the CNC that is connected, the type and number of motors,

and the power consumption of the other peripheral devices. Using the

expression given below, calculate the noise filter load current, and select

a noise filter so that the load current does not exceed the rated current of

the filter. Recommended noise filters are given in (12) of Section 2.2.3.

Obtaining the load current of a noise filter

The load current of a noise filter is the sum of the CNC input current, PSM

input current, and current consumption under the other loads.

Load current

(Arms)

CNC input

current

(Arms)

PSM input

current

(Arms)

Current con-

sumption under

other loads

(Arms)

=+ Σ+

(Note 1) (Note 2)

NOTE

1 The CNC input current is determined by the number of

PSUs (power supply units). Calculate the CNC input current

from the following expression:

CNC input current (Arms) = 5 (Arms) x number of PSUs

Normally, a CNC has one PSU. The FS15 multiaxis control

system has two PSUs.

2 For details of how to obtain the PSM input current, see

Sections 4.1.1 or 4.2.1.

3 Attach a noise suppressor such as a spark killer to the

magnetic contactor driving coil. When more than one PSM

is connected, sum the input currents of the PSMs.
