11. OPTION RELATED TO SPINDLE

B–65162E/03

434

(b) Orientation command (ORCMA)

D This signal is used to stop the spindle at a specified position to

attach/detach a workpiece.

D When this signal is set to 1, the spindle, if rotating, is decelerated

immediately and stops at a specified position.

D If an orientation command is issued for safety, set the spindle forward

rotation/reverse rotation command (SFRA/SFRA) to 0. Then, the

spindle does not start rotating even if ORCMA is set to 0 during tool

replacement.

D Ensure that this signal is set to 0 by the workpiece attachment /

detachment completion signal.

D Ensure that the orientation command signal is set to 0 when the power

is turned on.

D Reset the orientation command signal to 0 when an emergency stop is

initiated during orientation.

D When there are two or more speed change gear stages between the

spindle and spindle motor, these signals are used to select a spindle

control parameter (position gain, gear ratio, velocity loop gain).

D Depending on the clutch or gear state, make settings according to the

table below. Names such as HIGH GEAR are given only for

convenience. Arbitrary names may be assigned to the actual gears.

CTH1A CTH2A

0 0 HIGH GEAR

0 1 MEDIUM HIGH GEAR

1 0 MEDIUM LOW GEAR

1 1 LOW GEAR

(d) Spindle orientation stop position change command (INDXA)

D In orientation of external stop position setting type, this signal is used

to orient the spindle to a different position immediately after spindle

orientation.

This signal is valid when the spindle orientation command (ORCMA)

is set to 1.

D When this signal makes a transition from 1 to 0, the spindle is oriented

within one rotation to the position specified by new stop position data

(SHA11 to SHA00) (arbitrary position within one rotation specified

by an absolute position command).

D The direction of orientation is specified by the shortcut rotation

command (NRROA) or rotation direction command (ROTAA).

D This function is enabled when the CNC parameter for an orientation

function of external stop position setting type is set.

(e) Shortcut rotation command for spindle orientation stop position modification (NRROA)

D This signal is used to specify a rotation direction when the spindle is

oriented to a different position immediately after spindle orientation.

This signal is used for shortcut rotation (within "180_) to the next

stop position.
