Alpha Series AC Servo Amplifier Descriptions Page 305

Descriptions

Page of 699

/ 699

B–65162E/03

9.CONNECTION

285

High–resolution

magnetic pulse

coder preamplifier

(Motor side)

Detailed description of the connection of cable K18

SPM

JY2

(3)

(4)

(17)

(19)

(1)

(2)

(5)

(6)

(7)

(8)

(9), (18), (20)

(12), (14), (16)

(13)

(15)

(10)

VA2

*VA2

VB2

*VB2

*MZ

*PA

*PB

+5V

OH1

OH2

RA1

RB1

RA3

RB3

+5V

OH1

OH2

CN2

(16)

(17)

(18)

(19)

(14)

(15)

(10)

(11)

(12)

(13)

(4), (5), (6)

(1), (2), (3)

(8)

(9)

(7)

Cable specification : Six 0.18mm

twisted pairs

Six 0.5mm

wires

Common shielded cable

Required connector (HIROSE)

Connector FI40B–20S

Housing FI–20–CV5

Cable: +5V, 0V...three 0.18 mm

wires each

PA, *PA, PB, *PB, MZ, *MZ, VA2, *VA2, VB2, *VB2, OH1, OH2...0.18 mm

twisted pair

Recommended cable specification (wire only): A66L–0001–0367

See Appendix C for details.

Required connector (HIROSE)

HR22–12WTPA–20S (Note)

FI40B–20S–CV5

(Note)In addition to a soldering type, a crimping type can be selected.

Crimping type

Crimp pin : HR22–SC–122

(20 pins are required for each connector.)

Connector housing: HR22–12WTPA–20SC

Soldering type : HR22–12WTPA–20S

Crimping type connectors require the use of the following crimping tool:

Crimping tool specification: HR22–TA–2428HC (HIROSE)
