10. INTERFACE SIGNALS

B–65162E/03

362

Symbol DescriptionSignal

RSLA, B

Speed range

switching

request signal

Used to select the output characteristics in speed range

swiching control.

0 : High-speed range

1 : Low-speed range

RCHA, B

Power line sta-

tus check sig-

nal

Used for the speed range switching function.

0 : High-speed range

1 : Low-speed range

INDXA, B

Orientation

stop position

change signal

Used for the stop position external

setting type orientation.

New stop position data is obtained

when the level of the signal is

changed from 1 to 0.

Then, the spindle is moved to the

new stop position, and is stopped.

ROTAA, B

Rotation direc-

tion command

while changing

the orientation

stop position

Used for the stop position external setting type orienta-

tion.

0 : CCW (counterclockwise)

1 : CW (clockwise)

NRROA, B

Short-distant

movement

command while

changing the

orientation stop

position

Used for the stop position external setting type orienta-

tion.

0 : The rotation direction depends on the setting of

ROTA (= bit 1)

1 : Short-distance movement control (within "180°)

DEFMDA, B

Differential

mode com-

mand

Used for the spindle differential control mode

1 : Differential control mode

OVRA, B

Analog over-

ride command

0 : Analog override is disabled.

1 : Analog override is enabled.

INCDA, B

Incremental

command

1 : Incremental command spindle orientation

0 : Normal orientation

MFNHGA, B

Main-spindle

MCC status

signal while

changing

spindles

0 : The MCC in the main spindle is opened.

1 : The MCC in the main spindle is closed.

RCHHGA, B

High–speed

MCC status

signal while

changing

speed range

0 : The MCC for high speed is opened.

1 : The MCC for high speed is closed.

MORCMA, B

Command for

spindle orienta-

tion with a

magnetic sen-

sor

1 : Spindle orientation with the magnetic sensor is con-

trolled.

SLVA, B

Slave operation

command

0 : Slave operation control is disable.

1 : Slave operation control is enable.

MPOFA, B

Motor power

stop signal

1 : Motor power stop

”1”

”0”
