B–65162E/03

4. SPECIFICATIONS

[How to calculate the power equipment capacity]

Calculate the power equipment capacity using the formula below.

Power supply

capacity (kVA)

Rated capacity calculated in Section 3.3 or 3.4 (kW)

Rated capacity of power supply module (kW)

Power supply capacity of power supply

module having rated output (kVA)

(See Table 4.1.1 (a), (b))

NOTE

Select a power supply for which, when the motor is

accelerated, the input voltage variation does not exceed 7%

(see Subsection 5.2.1 for details).

[How to calculate the input current of the PSM (PSMR)]

Calculate the input current of the PSM (PSMR) by using the formula

below. Refer to the result when selecting the MCC, power cable, and

circuit breaker 1, to be connected to the PSM input section.

PSM input

current (Arms)

Power equipment capacity (kVA)

3 Nominal supply voltage (Vrms)

× 1.2 (margin)

NOTE

Normally, assume the nominal supply voltage (Vrms) to be

200Vrms.
