Alpha Series AC Servo Amplifier Descriptions Page 639

Descriptions
F. SPECIFICATIONS OF CABLES
B–65162E/03
APPENDIX
620
Use
FANUC specification
(complete cable)
Specification
Sym-
bol
α18
αP30
(Motor
power line)
K10
α22
αP40
αP50
αP60
(Motor
power line)
K10
α30 (motor
power line)
K10
PSM–45
(Power line)
K10
NOTE
1 Heat–resistant cable: Furukawa Electric Co., Ltd.
Contact: 03(3286)3144
LMFC (Fire–retardant Polyflex electric cable, Maximum
allowable conductor temperature: 105°C)
2 Crimp terminal: Nichifu Contact: 03(3452)7381 8–4S
3 Crimp terminal: Japan Crimp Terminal Production 38–6S
Heat resistive vinyle cable 14mm
2
(88/0.45)
SPM side (TB2)
T14–6
φ7
Motor side
T14–8
Heat resistive vinyle cable 22mm
2
(7/20/0.45)
SPM side (TB2)
T22–6
φ9.6
Motor side
T22–8
Heat–resistive vinyle cable (Note 1) 38mm
2
(7/34/0.45)3 each
SPM side (TB2)
T38–6S (Note 3)
φ11.7
Motor side
T38–10
Heat–resistive vinyle cable (Note 1) 22mm
2
(7/20/0.45)1 each
SPM side (TB2)
T22–6
φ9.6
Motor side
T22–10
Heat–resistive vinyle cable (Note 1) 50mm
2
(19/16/0.45)3 each
SPM side (TB2)
T60–10
φ13.6
Motor side
T60–10
Heat–resistive vinyle cable (Note 1) 22mm
2
(7/20/0.45)1 each
SPM side (TB2)
T22–6
φ9.6
Motor side
T22–10
