10. INTERFACE SIGNALS

B–65162E/03

364

(1) 1st Spindle Signal Address

FS0

FS0–TT

HEAD2

FS15

(Note 1)

FS16

Path 1 Path 2

#7 #6 #5 #4 #3 #2 #1 #0

F281 F1481 F229 F045 F1045 ORARA

TLMA LDT2A LDT1A SARA SDTA SSTA ALMA

F282 F1482 F228 F046 F1046 MOAR2A MOAR1A POAR2A SLVSA RCFNA RCHPA CFINA CHPA

F283 F1483 F231 F047 F1047 EXOFA SORENA MSOVRA INCSTA PC1DTA

F172 F1372 F036 F1036 R08O R07O R06O R05O R04O R03O R02O R01O

F173 F1373 F037 F1037 R12O R11O R10O R09O

F010

(F006)

(Note 2)

RO15 RO14 RO13 RO12 RO11 RO10 RO09 RO08

F001

(F001)

RO07 RO06 RO05 RO04 RO03 RO02 RO01 RO00

F150 F1350 F007 F1007 SF MF

SF MF

F149 F1349 F001 F1001 ENB

F164 F1364 F038 F1038 ENB3 ENB2 SCLP SUCLP

SPCO SPBO SPAO SPAL SSLP SUCLP

F154 F1354 F035 F1035 SPAL

F152 F1352 F034 F1034 GR30 GR20 GR10

F001 CSS

F002 F1002 CSS

F178 F044 F1044 SYCAL FSPPH FSPSY FSCSL

F67, 71,

...

MCNTR1,

2, ...

F111 MSPPHS MSPSYC SPSYAL

F040 RTAP

F020 F025 F1025 S31 S30 S29 S28 S27 S26 S25 S24

F021 F024 F1024 S23 S22 S21 S20 S19 S18 S17 S16

F022 F023 F1023 S15 S14 S13 S12 S11 S10 S09 S08

F023 F022 F1022 S07 S06 S05 S04 S03 S02 S01 S00

F012 F041 F1041 AR15 AR14 AR13 AR12 AR11 AR10 AR09 AR08

F013 F040 F1040 AR07 AR06 AR05 AR04 AR03 AR02 AR01 AR00

F232 SLDM15 SLDM14 SLDM13 SLDM12 SLDM11 SLDM10 SLDM09 SLDM08

F233 SLDM07 SLDM06 SLDM05 SLDM04 SLDM03 SLDM02 SLDM01 SLDM00

F234 SSPD15 SSPD14 SSPD13 SSPD12 SSPD11 SSPD10 SSPD09 SSPD08

F235 SSPD07 SSPD06 SSPD05 SSPD04 SSPD03 SSPD02 SSPD01 SSPD00

F236 SSPAA7 SSPAA6 SSPAA5 SSPAA4 SSPAA3 SSPAA2 SSPAA1 SSPAA0

NOTE

1 The addresses listed under ”FS15” are for the PMC–NA.

Refer to the FS15 Connection Manual for the PMC–NB

addresses.

2 The addresses in parentheses are used for 15–TT.

10.2.2

Spindle Control DO

Signals (CNC to PMC)
