11. OPTION RELATED TO SPINDLE

B–65162E/03

436

(2) Output Signals (CNC to PMC)

(a) Signal addresses

#7 #6 #5 #4 #3 #2 #1 #0

FS0 FS15 FS16

ORARA TLMA LDTA SARA SDTA SSTA ALMA

1st : F281 F229 F405

First spindle control output signal

#7 #6 #5 #4 #3 #2 #1 #0

FS0 FS15 FS16

ORARB TLMB LDTB SARB SDTB SSTB ALMB

1st : F285 F245 F049

Second spindle control output signals

(b) Orientation completion signal (ORARA)

D This signal is set to 1 when the spindle stops near a specified position

(within "1_, for example) after an orientation command is entered.

ORARA is set to 1 when the following conditions are satisfied:

– ORCMA = 1

– Speed zero signal = 1

– The spindle stops near a specified position.

The third condition (near a specified position) is set using parameter

No. 4075 (FS16) for orientation completion signal detection level

specification. When all of the three conditions above are satisfied, the

orientation completion signal is output. If the orientation completion

signal is not issued despite sufficient time having elapsed after the

input of an orientation command, an error is assumed. Ensure that

such an error is detected with the power magnetics sequence, and that

an orientation alarm is issued.

D Only after this signal is set to 1, start workpiece attachment or

detachment.

D The orientation completion signal is output when the spindle is within

about "1_ of a specified position. This means that this signal does

not represent a complete stop.

D When the spindle is displaced from a point near a specified position

by an external force, this signal is set to 0.
