11. OPTION RELATED TO SPINDLE

B–65162E/03

446

Z NRROA and ROTAA determine the direction of rotation.

When NRROA is set to 1, the spindle rotates from the current

stop position to the specified stop position by taking the shorter

route (within "180°). When NRROA is set to 0, ROTAA

determines the direction of rotation.

The following parameters are added when the function for externally

setting incremental commands is used for position coder method spindle

orientation Refer to the Parameter Manual and each CNC manual for

details.

Parameter No.

Description

FS0 FS15 FS16

Description

0080

#3, 2

5609

#3, 2

3702

#3, 2

Whether the function for externally setting incremental commands is

used (#2: First spindle, #3: Second spindle)

6292 3472 4328

Command multiplication for data for externally setting incremental com-

mands

This section describes a spindle orientation function. This function is

implemented in a system consisting of an external one–rotation signal

switch (proximity switch) mounted on the spindle, and a spindle motor

having a built–in sensor and connected to the spindle with an arbitrary

gear ratio.

This function is similar to the position coder–based spindle orientation

function except for the items listed below.

1) A fixed orientation must be specified by setting 1 in bit 3 of parameter

No. 4003.

2) The detection of a one–rotation signal begins after the orientation

speed is reached.

NOTE

1 See Section 11.1.1 for descriptions about anything other

than external one–rotation signal handling (position coder

– based spindle orientation).

2 The αC series does not support this function.

11.1.3.5

Parameters

11.1.4

Spindle Orientation by

External One Rotation

Signal

11.1.4.1

General
