3. HOW TO SELECT THE POWER SUPPLY MODULE

B–65162E/03

For how to select a power supply module (PSMV–HV), see Section 3.3,

and for the rated output capacity, see Table 4.2.1 (3).

When two α6/3000 servo motors, one α22/2000 servo motor and one α3

spindle motor are used

α6/3000 servo motor

Continuous rated output : 1.4 kW

Accelerating maximum output : 6.2 kW

α22/2000 servo motor

Continuous rated output : 3.8 kW

Accelerating maximum output : 7.5 kW

α3 spindle motor

Continuous rated output : 3.7 kW

Accelerating maximum output : 6.6 kW

yΣ

Rated output capacity of power supply module

×1.15+Σ

Continuous rated output

of spindle motor

Continuous rated output

of servo motor

×0.6

=3.7 1.15\(1.4×2+3.8) 0.6

= 8.215 (1)

Maximum output capacity of power supply module

yΣ

Accelerating maximum

output of spindle motor

+Σ

Accelerating maximum output

of servo motor (for simultaneous

acceleration/deceleration axis)

= 6.6×(6.2 2+7.5) 0.6

= 18.54 (2)

As the rated output capacity of the power supply module is less than 11

kW, the following formula is used for calculating the maximum output ca-

pacity:

×0.6

Based on (1) and (2), the PSM–11HV is selected.

3.5

SELECTING A

POWER SUPPLY

MODULE (PSMV–HV)

3.5.1

Example of Selecting a

Power Supply Module

(PSMV–HV)
