B–65162E/03

11. OPTION RELATED TO SPINDLE

479

(1) DI Signal (PMC to CNC)

(a) Signal Addresses

CON

(M)

#6 #5 #4 #3 #2 #1 #0

COFF

(T)

G123

FS0 FS15 FS16

MRDYA ORCMA SFRA SRVA CTH1A CTH2A TLMHA TLMLA

RCHA RSLA INTGA SOCNA MCFNA SPSLA *ESPA ARSTA

CON

(T/M)

G027

SCTR1, 2 .

G67, G71 . .

G229 G227 G070

G230 G226 G071

This signal switches between the spindle rotation control mode and Cs

contouring control mode.

Before switching from the Cs contouring control mode to the spindle

rotation control mode, check that the spindle move command has

terminated. Switching from the spindle rotation control mode to the Cs

contouring control mode is enabled even when the spindle is rotating.

In this case, spindle rotation is decelerated then stopped, and the modes

are changed. For safe operation, be sure to reset the spindle speed

command (S command).

COFF 0 : Cs contouring control mode

(FS0) 1 : Spindle rotation control mode

CON 0 : Spindle rotation control mode

(FS0, FS16) 1 : Cs contouring control mode

SCNTR1, 2, ... 0 : Spindle rotation control mode

(FS15) 1 : Cs contouring control mode

(2) DO Signal (CNC to PMC)

(b) Signal Addresses

#7 #6 #5 #4 #3 #2 #1

FSCDL

F178 F004

FS0 FS15 FS16

MCNTR1, 2 .

F67, F71 . .

This signal posts the completion of switching between the spindle

rotation control mode and Cs contouring control mode.

FSCSL 0 : Spindle rotation control mode

(FS0C, FS16) 1 : Cs contouring control mode

MCNTR1, 2, ... 0 : Spindle rotation control mode

(FS15) 1 : Cs contouring control mode

11.3.4

DI and DO Signals
