9. CONNECTION

B–65162E/03

286

Cable specification : Five 0.18mm

twisted pairs

Six 0.5mm

wires

Common shielded cable

Detailed description of the connection of cable K19

SPM JY5

(5)

(6)

(7)

(8)

(1), (2), (3)

(9), (18), (20)

(12), (14), (16)

(10)

(16)

(17)

(18)

(19)

(14)

(15)

(10)

(11)

(12)

(13)

(4), (5), (6)

RA1

+5V

RB1

+5V

RA1

RB1

Required connector (HIROSE)

Connector FI40A–20S

Housing FI–20–CV5

Cable: +5V, 0V...three 0.18 mm

wires each

A1, RA1, B1, RB1, Z, *Z, A3, RA2, B3, RB3...0.18 mm

twisted pair

Recommended cable (wire only): A66L–0001–0367

See Appendix C for details.

Required connector (HIROSE)

HR22–12WTPA–20S (Note)

FI40A–20S–CV5

CN2

(3)

(4)

(17)

(19)

(1)

(2)

(7)

High–resolution

magnetic pulse

coder preamplifier

(Spindle side)

(NOTE) In addition to the soldering type, a crimping type can also be selected.

RB3

RA3

RB3

RA3

Crimping type

Crimp pin : HR22–SC–122

(20 pins are required for each connector.)

Connector housing: HR22–12WTPA–20SC

Soldering type : HR22–12WTPA–20S

Crimping type connectors require the use of the following crimping tool:

Crimping tool specification: HR22–TA–2428HC (HIROSE)
