Alpha Series AC Servo Amplifier Descriptions Page 41

Descriptions
B–65162E/03
2. CONFIGURATION AND ORDERING INFORMATION
21
(2) Capacitor module (PSMC–HV)
When using a PSM–HV, specify a capacitor module (PSMC–HV).
Category Name Ordering number
External dimensions
(H x W x D mm)
Remarks
PSMC–18HV A06B–6083–H218
38090172
For PSM–18HV
Standard
PSMC–30HV A06B–6083–H230
38090172
For PSM–30HV
PSMC–45HV A06B–6083–H245 380150222
For PSM–45HV and
PSM–75HV
(3) Power supply module (PSMV–HV)
Category Name Ordering number
External dimensions
(H x W x D mm)
Remarks
Standard PSMV–11HV A06B–6098–H111 380150307
NOTE
No capacitor module (PSMC–HV) is required.
(4) Servo amplifier module (SVM–HV)
The ordering drawing number differs depending on the interface with the CNC.
Specify an appropriate SVM–HV for the interface between the CNC and SVM–HV.
– Servo amplifier module (one axis)
(a) TYPE A and TYPE B interfaces
Category Name Ordering number
External dimensions
(H x W x D mm)
Remarks
SVM1–20HV A06B–6085–H102
Standard
SVM1–40HV A06B–6085–H103
38090307
SVM1–60HV A06B–6085–H104
(b) FSSB interface
Category Name Ordering number
External dimensions
(H x W x D mm)
Remarks
SVM1–20HV A06B–6097–H102
Standard
SVM1–40HV A06B–6097–H103
38090307
SVM1–60HV A06B–6097–H104
