3. HOW TO SELECT THE POWER SUPPLY MODULE

When selecting a power supply module (PSM–HV), calculate the rated

output capacity and maximum output capacity as explained below, then

select an appropriate PSM–HV that satisfies these calculated values.

Multiply the total continuous rated output of the spindle motors by a

coefficient (1.15), and also multiply the total continuous rated output of

the servo motors by a coefficient (0.6). Then, select a power supply

module so that the sum of the multiplication results does not exceed the

rated output capacity of the power supply module.

Rated output capacity of

power supply module

Spindle motor continuous

rated output

Servo motor continuous

rated output

yΣ ×1.15

+Σ ×0.6

When only one spindle amplifier module is connected to a power supply

module, the power supply module must be selected so that the 30–minute

rated output of the spindle motor does not exceed the rated output capacity

of the power supply module.

Rated output capacity of a power supply module y 30– minute rated out-

put of a spindle motor

For the rated output capacities of the power supply modules, see Table

4.2.1 (a). For the continuous rated outputs of the servo motors, see Table

3.7.1. For the continuous rated outputs of spindle motors, see Table 3.7.2.

Select a power supply module so that the sum of the total maximum

output of the spindle motors at acceleration and the total maximum output

of simultaneously accelerated/decelerated servo motors at acceleration

does not exceed the maximum output capacity of the power supply

module.

Maximum output capacity of

power supply module

maximum output of spindle

motors at acceleration

maximum output of servo motors at acceleration

(simultaneously accelerated/decelerated axes)

yΣ

+Σ

For the maximum output capacities of the power supply modules, see

Table 4.2.1 (a). For the maximum outputs of the servo motors at

acceleration, see Table 3.7.1. For the maximum outputs of the spindle

motors at acceleration, see Table 3.7.2.

3.6

SELECTING A

POWER SUPPLY

MODULE (PSM–HV)

3.6.1

Obtaining the Rated

Output Capacity of a

Power Supply Module

3.6.2

Obtaining the

Maximum Output

Capacity of a Power

Supply Module
