Alpha Series AC Servo Amplifier Descriptions Page 75

Descriptions

Page of 699

/ 699

B–65162E/03

3. HOW TO SELECT THE POWER SUPPLY MODULE

Select a power supply module that satisfies the rated output capacity and

maximum output capacity, calculated as follows:

Select a power supply module with a rated output not less than the sum

of the total continuous rated output of the spindle motors times 1.15, plus

the total continuous rated output of the servo motors times 0.6.

Rated output capacity of

power supply module

Continuous rated output

of spindle motor

Continuous rated output

of servo motor

yΣ ×1.15

+Σ ×0.6

When only one spindle amplifier module is to be connected to a power

supply module, select the power supply module so that the 30–minute

rated output of the spindle motor does not exceed the rated output capacity

of the power supply module.

Rated output capacity of a power supply module y 30– minute rated out-

put of a spindle motor

Table 4.1.1 (1) lists the rated output capacities of the power supply

modules. Table 3.7.1 lists the continuous rated outputs of the servo

motors. Table 3.7.2 list the continuous rated outputs of the spindle

motors.

Select a power supply module with a maximum output not less than the

sum of the total accelerating maximum output of the spindle motors and

the total accelerating maximum output of those servo motors that

accelerate/decelerate at the same time.

When the rated output capacity is 11 kW or less, calculate the maximum

output capacity according to 3.3.2 (a), below. When the rated output

capacity is 12 kW or more, calculate according to 3.3.2 (b).

(1) For a rated output capacity of 11 kW or less

Maximum output

of power supply module

Accelerating maximum

output of spindle motor

Accelerating maximum output of servo motor

(for simultaneous acceleration/deceleration axis)

yΣ ×1.15

+Σ

×0.6

When the obtained value at the right–hand side is 20 kW or more,

calculate the maximum output capacity according to 3.3.2 (b).

(2) For a rated output capacity of 12 kW or more

Maximum output

of power supply module

Accelerating maximum

output of spindle motor

Accelerating maximum output of servo motor

(for simultaneous acceleration/deceleration axis)

yΣ

+Σ

3.3

HOW TO SELECT THE

POWER SUPPLY

MODULE (PSM)

3.3.1

Rated Output Capacity

3.3.2

Maximum Output

Capacity of Power

Supply Module
