11. OPTION RELATED TO SPINDLE

433

No. Item Description

1 Position coder

Connected to a spindle on a one–to–one basis.

1024 pulses/rev (phase A signal, phase B signal)

1 pulse/rev (one–rotation signal)

2 Detection unit

0.088_

One spindle rotation (360_) is divided by 1024 4 (4096) pulses, and one

pulse unit (0.088_) is used as the detection unit.

360_/ 4096 pulses = 0.088_/ pulses

3 Positioning repeatability

"0.4_ (spindle angle)

This value does not include mechanical errors (such as the coupling back-

lash between the spindle and position coder).

Depending on the position gain adjustment, an error of one detection unit

(0.088_) may occur after orientation.

Torque maintained at orienta-

tion stop time

None

Orientation of external stop

position setting type

Enabled.

However, the INDX signal is valid only with the 9D12 series.

Spindle orientation of incre-

mental command type

Disabled

(1) Input Signals (PMC to CNC)

(a) Signal address

SHA07

SHA06

SHA05

SHA04

SHA03

SHA02

SHA01

SHA00

: G110 G231 G078

FS0 FS15 FS16

SHA11 SHA10 SHA09 SHA08

: G111 G230 G079

MRDYA ORCMA SFRA SRVA CTH1A CTH2A TLMHA

: G229 G227 G070

OVRA

NRROA ROTAA INDXA

: G231 G229 G072

First spindle control input signal

SHB07

SHB06

SHB05

SHB04

SHB03

SHB02

SHB01

SHB00

: G112 G239 G080

FS0 FS15 FS16

SHB11 SHB10 SHB09 SHB08

: G113 G238 G081

MRDYB ORCMB SFRB SRVB CTH1B CTH2B TLMHB

: G223 G235 G074

OVRB

NRROB ROTAB INDXB

: G235 G237 G076

Second spindle control input signals

11.1.2.4

Specifications

11.1.2.5

Signals
