B–65162E/03

11. OPTION RELATED TO SPINDLE

535

NOTE

1 When applying differential speed control to rigid tapping

(differential speed rigid tapping), ensure that the sum of the

speed specified for rigid tapping and that of the first spindle

does not exceed the maximum speed of the second spindle.

2 The output torque of a motor generally decreases in high

speed areas. So, a larger acceleration/deceleration time

constant must be set for rigid tapping.

3 For the method of rigid tapping, refer to the CNC manual.

The table below lists the parameters related to the differential speed

control function. Refer to the Parameter manual for details.

Parameter No.

Description

FS0 FS15 FS16

Description

6500#5 3000#5 4000#5 Whether the differential speed control function is used (Set to 1.)

6500#6 3000#6 4000#6 Setting of the differential speed direction

6500#0 3000#0 4000#0 Rotational direction of the spindle and motor

6500#2 3000#2 4000#2 Mounting orientation of the position coder

6500#7 3000#7 4000#7 Setting of the number of position coder feedback pulses for spindle 1.

6501#2 3001#2 4001#2 Whether the position coder signal is used

6502#5 3002#5 4002#5 Setting of the rotation direction signal function in the servo mode

6503

#7, 6, 4

3003

#7, 6, 4

4003

#7, 6, 4

Setting of the position coder signal

11.8.7

Parameters
