10. INTERFACE SIGNALS

B–65162E/03

392

(2) 2nd Spindle Signal Address

FS0

FS0–TT

HEAD2

FS15 FS16 #7 #6 #5 #4 #3 #2 #1 #0

G223 G1429 G235 G074 MRDYB

ORCMB SFRB SRVB CTH1B CTH2B TLMHB

G234 G1433 G234 G075 INTGB

*ESPB

ARSTB

G235 G1434 G237 G076 OVRB

G236 G1435 G236 G077 MPOFB

G112 G1316 G239 G080 SHB07 SHB06 SHB05 SHB04 SHB03 SHB02 SHB01 SHB00

G113 G1312 G238 G081 SHB11 SHB10 SHB09 SHB08

G034 R0812 R0712 R06I2 R05I2 R04I2 R03I2 R02I2 R01I2

G035 SIND2 SSIN2 SGN2 R12I2 R11I2 R10I2 R09I2

G232 RISGNB RIB12 RIB11 RIB10 RIB9 RIB8

G233 RIB7 RIB6 RIB5 RIB4 RIB3 RIB2 RIB1 RIB0

G106 G1306 M2R08I M2R07I M2R06I M2R05I M2R04I M2R03I M2R02I M2R01I

G107 G1307 M2SIND M2SSIN M2SGN M2R12I M2R11I M2R10I M2R09I

* Valid only for αC spindle software 9D12 series.
