Alpha Series AC Servo Amplifier Descriptions Page 493

Descriptions

Page of 699

/ 699

B–65162E/03

11. OPTION RELATED TO SPINDLE

473

Parameter No.

Description

FS0

M/T/TT Description

FS16

M/T

FS15

M/T

First

spindle

Description

FS16

M/T

FS15

M/T

Second

spindle

In–position width, positional deviation limit (Continued)

(M series)

0619

(T series)

0401

5755 5301 Spindle in–position width

(M series)

0620

(T series)

0402

1837

5310

( 5314 )

Positional deviation limit during movement on the tapping axis

(M series)

0621

(T series)

0403

5754 5311 Positional deviation limit during spindle movement

(M series)

0622

(T series)

0404

1829 5312 Positional deviation limit when the tapping axis is stopped

(M series)

0623

(T series)

0405

––– 5313 Positional deviation limit when the spindle is stopped

Setting related to orientation operation (reference position return) at the start of rigid tapping

(M series)

0388#3

Based on

machin-

ing pro-

grams

(M series)

5202#0

Whether to perform spindle orientation at the start of rigid tap-

ping

6574 3074 4074 Reference position return feedrate at rigid tapping time

6500#4 3000#4 4000#4 Reference position return direction at rigid tapping time

6573 3073 4073 Grid shift amount at rigid tapping time

6591 3091 4091

Position gain change ratio in reference position return opera-

tion at rigid tapping time

Others

6599 6939 3099 4099 Delay for motor activation (α series)

6597 6937 3097 4097 Delay for motor activation (αC series)

(M series)

0255

(T series)

0214 to

0217

5604#2

5756

5791 to

5794

5321 to

5324

Spindle backlash amount

––– ––– ––– 5214 Setting of a synchronization error at rigid tapping time

––– ––– ––– 5204#0

Indication of a synchronization error at rigid tapping time. (To

be set to 0)
