3. HOW TO SELECT THE POWER SUPPLY MODULE
B–65162E/03
48
First, select a servo motor, based on the machine specifications. Then,
select an appropriate servo amplifier module for the selected servo motor.
For combinations of servo motors and servo amplifier modules, see
Sections 3.1.1 and 3.1.2.
Table 3.1 (1)
Table.3.1 (a) Specifications
No. Specification
Number of
connected axes
Input
voltage
Interface with
CNC (Note)
1 A06B–6079–H1jj 1 200V TYPE A & B
2 A06B–6079–H2jj 2 200V TYPE A & B
3 A06B–6079–H3jj 3 200V TYPE A
4 A06B–6080–H3jj 3 200V TYPE B
5 A06B–6096–H1jj 1 200V FSSB
6 A06B–6096–H2jj 2 200V FSSB
7 A06B–6096–H3jj 3 200V FSSB
8 A06B–6085–H1jj 1 400V TYPE A & B
9 A06B–6085–H2jj 2 400V TYPE A & B
10 A06B–6097–H1jj 1 400V FSSB
11 A06B–6097–H2jj 2 400V FSSB
NOTE
There are three interfaces with the CNC: Type A, Type B,
and FSSB. Check the interface with the CNC being used,
then select an appropriate servo amplifier module.
