Alpha Series AC Servo Amplifier Descriptions Page 383

Descriptions

Page of 699

/ 699

B–65162E/03

10. INTERFACE SIGNALS

363

Symbol DescriptionSignal

DSCNA, B

Broken–wire

detection dis-

able signal

Used if a feedback loop between the amplifier and motor

is to be disconnected.

0 : Enables broken–wire and overheat detection.

1 : Disables broken–wire and overheat detection.

R12I - R01I

SGN, SSIN

SIND

RI12 - RI00

RISGN

Spindle speed

command

Specifies a spindle speed command.

SHA11 - SHA00

SHB11 - SHB00

Stop position

command for

spindle orienta-

tion with a posi-

tion coder

The stop position is specified externally spindle orienta-

tion with the position coder.

*SSTP

Spindle stop

signal

0 : Velocity command voltage = 0

1 : Velocity command voltage = specified value

SOR

Spindle

orientation in

progress

1 : Outputs the velocity command specified with the

parameter.

SAR

Velocity

reached signal

1 : The actual spindle speed reaches the specified

speed.

FIN

M function

completion sig-

nal

1 : The M function is completed.

CON, COFF

SCNTR1, 2 . .

Cs contour

control com-

mand

Specifies the Cs contour control mode .

GR1, 2

GS1, 2, 4

Gear select

signal (T-se-

ries)

Used for velocity command calculation under constant

surface speed control

*SUCPF

*SEUSL

Spindle un-

clamp signal

*SCPF

*SEUCL

Spindle clamp

signal

Used for spindle positioning control

SPSTP

Spindle stop

check signal

SPSYC

Spindle speed

synchroniza-

tion control

command

1 : Spindle speed synchronization control

SPPHS

Spindle phase

synchroniza-

tion control

command

1 : Spindle phase synchronization control

RGTP

RGTAP

Rigid tapping

command

1 : Rigid tapping control
