12. DETECTORS FOR THE SPINDLE

B–65162E/03

546

NOTE

– Use the BZ sensor at temperatures not exceeding 80°C.

– The BZ sensor is a precision device. It must be handled with care. In particular, ensure that

no force is applied to the S section.

– The sensor is an electronic device. Provide dust and drip protection on the machine so that

the sensor is not exposed to chips, oil, water, or any other harmful substance.

– Those dimensions that are marked with an asterisk (*) are the dimensions of the sensor

mounting ring. Design a socket and spigot joint on the machine side to match the dimensions.

If a socket joint on the machine side is designed incorrectly, an incorrect signal may be output.

– The gap between the sensor and detection ring is adjusted beforehand. However, an output

signal may not satisfy the specified value due to a socket and spigot joint error. Check the

output signals when mounting a sensor. If an output signal does not satisfy a specified value,

adjust the gap. For information about the output signal level for gap adjustment, refer to Part

II of ”FANUC Built–in AC Spindle Motor α Series Descriptions (B–65202EN).”

– Make a shielded wire connection.

– To ensure ease of maintenance, install a sensor in a location where it can be replaced easily.

– The detection ring of a sensor can be exchanged with another sensor provided the sensors

have the same drawing number.

– A sensor and detection ring cannot be combined if the detection ring is designed for a drawing

number different from that of the sensor.

– A mating connector (accessory) is provided with the BZ sensor.
