0i/0i Mate - Model C Parameter manual Page 146

Parameter manual
4.DESCRIPTION OF PARAMETERS B-64120EN/01
- 134 -
No. Data type Contents
2058 Word axis
Ｄ phase current limit (PALPH)
2059 Word axis Counter electromotive force compensation (EMFBAS)
2060 Word axis Torque limit
2062 Word axis Overload protection coefficient (OVC1)
2063 Word axis Overload protection coefficient (OVC2)
2064 Word axis Soft disconnection alarm level
2065 Word axis Overload protection coefficient (OCVLMT)
2066 Word axis Acceleration feedback gain
2067 Word axis Torque command filter
2068 Word axis Feed forward coefficient
2069 Word axis Velocity feed forward coefficient
2070 Word axis Backlash acceleration timing
2071 Word axis Backlash acceleration effective duration, time during which the static friction
compensation function is enabled
2072 Word axis Static friction compensation
2073 Word axis Stop judgment parameter
2074 Word axis Velocity-dependent current loop gain
2077 Word axis Overshoot prevention counter
2078 Word axis Conversion coefficient for dual position feedback (numerator)
2079 Word axis Conversion coefficient for dual position feedback (denominator)
2080 Word axis First-order lag time constant for dual position feedback
2081 Word axis Zero width for dual position feedback
2082 Word axis Backlash acceleration stop amount
2083 Word axis Brake control timer (ms)
2084 Word axis Flexible feed gear (numerator)
2085 Word axis Flexible feed gear (denominator)
2086 Word axis Rated current parameter
2087 Word axis Torque offset /pre-loaded value in tandem control
2088 Word axis Machine velocity feedback coefficient gain
2089 Word axis Backlash acceleration base pulse
2091 Word axis Non-linear control parameter
2092 Word axis Look-ahead feed forward coefficient
2094 Word axis Backlash acceleration in negative direction
2095 Word axis Feed-forward timing adjustment coefficient
2097 Word axis Static friction compensation stop parameter
2098 Word axis Current phase lead compensation coefficient
2099 Word axis N-pulse suppression level
2101 Word axis Overshoot compensation effective level
2102 Word axis Final clamp value for actual current limit
2103 Word axis Amount of track back upon detection of unexpected disturbance torque
2104 Word axis Abnormal load detection alarm level during cutting (for cutting when switch function is
used)
2105 Word axis Torque constant
2107 Word axis Velocity loop gain override
2109 Word axis Fine acceleration/deceleration time constant (for cutting when switch function is used)
2110 Word axis Magnetic saturation compensation (base/coefficient)
2111 Word axis Deceleration torque limit (base/coefficient)
2112 Word axis AMR conversion coefficient 1
2113 Word axis Attenuation center frequency (Hz) of vibration-damping filter 1
2114 Word axis Stage 2 acceleration amount override for two-stage backlash acceleration
2116 Word axis Abnormal load detection, dynamic friction compensation value
2118 Word axis Excessive error level between semi-closed and closed loops
2119 Word axis Stop level with variable proportional gain
